G21 Disc Brake Gravel Frameset
Regular price $2,190.00
Unit price per
Our famous gravel bike for everything from gravel racing to bike-packing. Huge clearance for the roughest of conditions.
UCI Approved: Yes
Including Parts: G21 Frame, Fork, Handlebar, Seatpost
Frame:
Size: 45cm, 49cm, 52cm, 54cm, 56cm, 58cm, 60cm
Material: High Modulus Toray 800 Carbon Fiber
Color: Chromatic Grey / Snowfrost White / Custom Painting
BB: BBT-47
Headtube: Straight 1-1/2”
Rear Dropout: 12*142 Thru Axle
Rear Derailleur Hanger: Replaceable
Frame Weight: 980g+/-50g (49cm)
Handlebar:
Handlebar Size: 400mm,420mm,440mm
Stem Size: 80mm/90mm/100mm/110mm
Handlebar Weight: 340+/-15g (420x90)
Fork & Seatpost:
Fork: 1-1/8" to 1-1/2" Tapered Steerer, 12*100 Thru Axle
Fork Weight: 420g+/-15g
Seatpost Weight: 204+/-15g
Compatibility:
Brake Fitment: Flat Mount Disc
Cable Routing: Internal
Bottle Mounts : 4
Mudguard Compatible: Yes
Cargo Rack Compatible: Yes
Max Tire Width: 700X53mm , 650BX2.1”
Accessories:
Handlebar Spacers: 3mm: 1pc, 5mm: 1pc, 10mm:3pcs
Front Axle: 1pc, Rear Axle: 1pc
Limited Rider Weight: 110KG
Warranty: 6 Years
Geometry:
| Size | A | B | C | D | E | F | G | H | I | L | M |
| 45cm | 450 | 510 | 373 | 512 | 79 | 75° | 69° | 79 | 433 | 47 | 401.5 |
| 49cm | 490 | 515 | 373 | 531 | 98.5 | 75.0° | 69.5° | 79 | 433 | 47 | 401.5 |
| 52cm | 520 | 536.4 | 379 | 549 | 107 | 74.0° | 70° | 79 | 433 | 47 | 401.5 |
| 54cm | 540 | 551 | 383 | 566 | 126 | 73.5° | 70° | 79 | 433 | 47 | 401.5 |
| 56cm | 560 | 566 | 387 | 586 | 145 | 73° | 72.2° | 79 | 433 | 47 | 401.5 |
| 58cm | 580 | 577 | 390 | 611 | 171 | 73.0° | 72.3° | 79 | 433 | 47 | 401.5 |
| 60cm | 610 | 592 | 396 | 640 | 200 | 73.0° | 72.6° | 79 | 433 | 47 | 401.5 |
Sizing & Fit:
The charts below show our recommended sizes based on height, but there are some other factors, like arm and leg length, that determine a great fit.
That’s why you’ll see some overlap in our recommendations.
| Size | XXS | XS | S | M | L | XL | XXL |
| 45CM | 49CM | 52CM | 54CM | 56CM | 58CM | 60CM | |
| Rider Height | 160-169CM | 166-175CM | 172-181CM | 178-187CM | 184-193CM | 190-196CM | >196CM |
| 5'2.9"-5'6.5" | 5'5.3"-5'8.9" | 5'8.1"-5'11.2" | 5'10"-6'1.6" | 6'0.4"-6'3.9" | 6'2.8"-6'5.1" | >6'5.1" |
LIGHTWEIGHT
G21 MONSTER GRAVEL EXPLORE NATURE, CONQUER CHALLENGES
G21 is good chooice for gravel racing or long-distance gravel riding
EPS+LATEX PRODUCTION TECH FOR HANDLEBAR AND FRAME
Moulded by one piece monobloc with EPS+LATEX tech makes the handlebar much stiffer and smoother internally, yet easier for cable routing.
As previously mentioned the G21 is moulded by new manufacturing process called EPS+Latex Tech. Unlike traditional methods like nylon bladders, latex is very flexible and can stretch, so the inside of the frame can be moulded more consistently. This new tech makes G21 incredibly smooth internally eliminating fold lines and creases for a more uniformed internal wall smoothness resulting in a stronger frame. It also simplifies the cable routing process and with this new tech, the frameset weight remains lower due to the extra resin overflow rate is higher and spreads more evenly during the moulding process.
Our H21 gravel handlebar are using the same tech as well.
FULLY INTERNAL CABLING
Internal cable routing results in external clean lines and improved aerodynamics with the cables completely hidden from view within our fully internal H21 integrated handlebar. The internal cable routing system is not only adding to the aesthetic qualities of the frame, but also makes cleaning the frame a simpler process.
TONS OF MOUNTS
This G21 has tons of mounting for bottle cages, fork panniers, rear panniers, and mudguards on both front and rear sides. We even make the front triangle high enough to ensure riders can mount a frame bag without sacrificing two bottle carrying capacity on the bike.
MASSIVE TIRE CLEARANCE
Up to 53c means you can fit a MTB 29 inch tire when you need to tackle bigger obstacles or to ride in very challenging terrain. However, smaller tire sizes like 45c are recommended for muddy condition rides and for a bike setup with mud guards to ensure there is enough room for mud built-up during the ride.
EXTRA COMPLIANCE FOR BETTER CONTROL
We purposely choose D-Shaped seatpost to give the rider a little bit of compliance on the rough road surface, combined with a bigger tire to act as its main suspension. G21 allows the rider to ignore small obstacles and focus on bike control.
6 YEARS OR LIFETIME WARRANTY
Durlable, Afforable, Quality Frameset We offer 6years quality warranty for the Frameset including the handlebars by H21.
Optional for lifetime warranty.
CRASH REPLACEMENT
We hope you don't need this but if you have a crash, we offer a 30% crash replacement discount on all wheels and framesets. Please contact us and we’ll do our very best to help you and ride again ASAP.
We always want to delivery the best products to our customers, we improved our G21 for 2023 to delivery the best performance
Check the video for more details
