R12 Disc Brake Bike Frameset

Regular price $1,650.00 Sale price $2,200.00

Unit price per

Size

The R12 is designed to make no compromise in terms of aero performance. With a large BB shell, you can be sure power transfer is outstanding. The R12 also allows for incredible flexibility of rider position. Take the R12 to challenge your best buds for the town sprint?

Frameset:R12 Frame+Fork+Handlebar+Seatpost

Frame Sizes:43cm,47cm,50cm,52cm,54cm,56cm,59cm

Handlebar Size:380mm,400mm,420mm,440mm

Stem Size:90mm/100mm/110mm/120mm

Material:High Modulus Toray 800 Carbon Fiber

Color: Hemidium / Emerald Green / Custom Painting

Carbon Weave:UD

Groupset Compatible:Machine and Di2 compatible

BB:BB386

Rear Dropout:12*142 Thru Axle

Rear derailleur hanger:Replacable

Headtube:1-1/2"

Fork:Aero Disc Brake Fork,Flat Mount,12*100 Thru Axle

Fork Offset:45°

Brake:Flat Mount Disc Brake

Max Tire Width:32mm

Cable:Internal cable

Frame Weight:950g(50cm)

Fork Weight:390g

Accessories: Handelbar Spacers 3mm: 1PC, 5mm: 1PC, 10mm: 3PCS

                     Front Axle 1PC, Rear Axle 1PC

Limited Rider Weight:110KG

Warranty: 6 Years

Geometry:

Size Dimension A B C D E F G H I J K L M
43CM 430 505 370.6 501.6 100 75° 70.5° 72 415 572.9 977 43 371
47CM 450 516 375.9 505 100 74.5° 71.5° 72 415 570.7 974.8 43 371
50CM 470 528 378.6 520.9 115 74° 72° 72 415 574.2 978.3 43 371
52CM 490 540 381 536.9 130 73.5° 72.5° 72 415 577.1 981.3 43 371
54cm 510 552 386 550 145.7 73° 73° 72 415 583.5 987.6 43 371
56CM 530 567 388.2 567.2 160 72.5° 73° 72 415 588.9 993.2 43 371
59CM 560 582 393 581.6 175 72° 73° 72 415 598.1 1002.4 43 371

Sizing & Fit:

The charts below show our recommended sizes based on height, but there are some other factors, like arm and leg length, that determine a great fit.

That¡¯s why you¡¯ll see some overlap in our recommendations.

Size XXS
43CM
XS
47CM
S
50CM
M
52CM
L
54CM
XL
56CM
XXL
59CM
Rider Height 155-163CM 160-168CM 165-173CM 170-178CM 175-183CM 180-188CM 185-193CM

PROROUTE CABLE SYSTEM FOR A CLEAN LOOK

The R12's internal cable routing system, known as the ProRoute system, is designed to accommodate both mechanical and electronic groupsets. This innovative feature keeps your cables tucked away and protected, resulting in a clean, streamlined appearance and reduced maintenance.

EPS+LATEX PRODUCTION TECH FOR HANDLEBAR AND FRAMES

Moulded by one piece monobloc with EPS+LATEX tech makes the handlebar much stiffer and smoother internally, yet easier for cable routing.

EPS+LATEX PRODUCTION TECH FOR HANDLEBAR AND FRAME

As previously mentioned the R12 is moulded by new manufacturing process called EPS+Latex Tech. Unlike traditional methods like nylon bladders, latex is very flexible and can stretch, so the inside of the frame can be moulded more consistently. This new tech makes R12 incredibly smooth internally eliminating fold lines and creases for a more uniformed internal wall smoothness resulting in a stronger frame. It also simplifies the cable routing process and with this new tech, the frameset weight remains lower due to the extra resin overflow rate is higher and spreads more evenly during the moulding process. Our H9 handlebar are using the same tech as well.

AERODYNAMIC DESIGN FOR UNRIVALED SPEEDS

The Yoeleo R12 2023 boasts a sleek, aerodynamic frame that minimizes drag and maximizes speed. Glide through the air and achieve your personal best on every ride with the R12's streamlined design.

 Beautiful Frame Curves for a Visually Appealing Aesthetic

The R12's elegant frame design not only offers performance benefits but also adds a visually appealing aesthetic to the bike, making it stand out from the crowd.

Enhanced Carbon Fiber Lay-up for Optimal Stiffness :

Experience the perfect balance of stiffness and lightweight performance with the R12's enhanced carbon fiber lay-up. This upgraded feature offers increased rigidity without adding extra weight, ensuring a responsive and nimble ride on every terrain.

Discover the Yoeleo R12 2023

The Ultimate Road Bike for Performance and Style

The Yoeleo R12 2023 carbon road bike redefines performance, innovation, and style for avid cyclists and passionate riders alike. With a multitude of unique selling points and cutting-edge features, the R12 offers an unparalleled cycling experience. In this comprehensive guide, we will delve into the standout features that make the Yoeleo R12 2023 the perfect road bike for every rider.

Advanced Paint Job for a Modern and Stylish Look

The R12 2023 model features a modern, stylish paint job that enhances the bike's visual appeal and highlights its innovative design features.

YOELEO TEST TEAM - 4MINDPROJECT

4Mindproject is a UCI continental cycling team who attend various UCI races throughout the year. R12 is our team machine.
