R11 Super Light Disc Brake Bike Frameset
Regular price
$1,750.00
Sale price
$2,025.00
Unit price per
Frameset: R11 Frame+Fork+Handlebar+Seatpost
Sizes: 49cm,52cm,54cm,56cm,59cm
Handlebar Size: 380mm,400mm,420mm,440mm
Stem Size: 90mm/100mm/110mm/120mm
Material: High Modulus Toray T1000 Carbon Fiber
Color: Arctic Ice / Ruby Red / Custom Painting
Carbon Weave: UD
Groupset Compatible: Machine and Di2 compatible
BB: BB86
Rear Dropout: 12*142 Thru Axle
Rear derailleur hanger: Replaceable
Headtube: 1-1/2” Straight
Fork: Aero Disc Brake Fork,Flat Mount,12*100 Thru Axle
Fork Offset: 45˚
Brake: Flat Mount Disc Brake
Max Tire Width: 32mm
Cable: Internal cable
Frame Weight:
Arctic Ice 980g (49cm) +/-50g
Ruby Red 1010g (49cm) +/-50g
Raw 890g (49cm) +/-50g
Fork Weight: 455+/-15g
Seatpost Weight: 204g+/-30g
Accessories: Handelbar Spacers 3mm: 1PC, 5mm: 1PC, 10mm: 2PCS, Headset Bearing Cap 10mm: 1PC
Front Axle: 1 PC, Rear Axle: 1 PC
Di2 Cover: 2PCS
Limited Rider Weight: 105KG
Warranty: 6 Years
Geometry:
| Size Dimension |
L Reach |
M Stack |
A Top Tube Length |
B Head Tube Length |
C Seat Tube Angle |
D Head Tube Angle |
E BB Drop |
F Chain Stay |
G Wheel Base |
H BB to Front Wheel |
I Fork Length |
J Fork Rake |
K Seat Tube Length |
| 49CM | 373 | 514 | 520 | 110 | 74° | 72.5° | 69 | 410 | 965 | 565 | 370 | 45 | 455 |
| 52CM | 384 | 523.5 | 535 | 120 | 74° | 72.5° | 69 | 410 | 975 | 579.5 | 370 | 45 | 475 |
| 54cm | 385 | 541 | 545 | 136 | 73.5° | 73° | 69 | 410 | 975 | 580.2 | 370 | 45 | 495 |
| 56CM | 394.5 | 557 | 560 | 155 | 73.5° | 73° | 69 | 410 | 990 | 594.9 | 370 | 45 | 515 |
| 59CM | 398 | 582 | 575 | 175 | 73° | 73.5° | 69 | 410 | 995 | 600 | 370 | 45 | 535 |
Sizing & Fit:
The charts below show our recommended sizes based on height, but there are some other factors, like arm and leg length, that determine a great fit.
That’s why you’ll see some overlap in our recommendations.
| Size | XS 49CM |
S 52CM |
M 54CM |
L 56CM |
XL 59CM |
| Rider Height | 165-173CM | 170-178CM | 175-183CM | 180-188CM | 185-193CM |
Super Light and Stiff
The R11 is super lightweight at just *850grms for the frame and 390grm for the fork (*size 54cm). This stiff and responsive frame means that with every pedal stroke your energy is transferred directly on to the ground, which is exactly where you want it. With fast handling for the descent’s, it makes the perfect partner. The only thing left to do is to see which hill you want to climb next?
EPS+LATEX PRODUCTION TECH FOR HANDLEBAR AND FRAME
Moulded by one piece monobloc with EPS+LATEX tech makes the handlebar much stiffer and smoother internally, yet easier for cable routing.
EPS+LATEX PRODUCTION TECH FOR HANDLEBAR AND FRAME
As previously mentioned the R11 is moulded by new manufacturing process called EPS+Latex Tech. Unlike traditional methods like nylon bladders, latex is very flexible and can stretch, so the inside of the frame can be moulded more consistently. This new tech makes R11 incredibly smooth internally eliminating fold lines and creases for a more uniformed internal wall smoothness resulting in a stronger frame. It also simplifies the cable routing process and with this new tech, the frameset weight remains lower due to the extra resin overflow rate is higher and spreads more evenly during the moulding process. Our H9 handlebar are using the same tech as well.
Fully Internal Cable Routing
Internal cable routing results in external clean lines and improved aerodynamics with the cables completely hidden from view within our fully internal H9v2 integrated handlebar. The internal cable routing system is not only adding to the aesthetic qualities of the frame, but also makes cleaning the bike a simpler process.
EXTRA COMPLIANCE FOR BETTER CONTROL
We purposely choose D-Shaped seatpost to give the rider a little bit of compliance on the rough road surface, combined with a bigger tire to act as its main suspension. R11 allows the rider to ignore small obstacles and focus on bike control.
Fit 32C Tyres
The latest research shows that wider tyres with lower pressures produce lower rolling resistance while improving grip. Riders can now choose up to a 32C tyre which is ideal for the demanding uneven road surfaces we encounter as riders and has the added benefit of inspiring greater confidence at speed knowing you have more control in the palm of your hand.
UCI Approved
R11 DB is UCI Approved
6 YEARS OR LIFETIME WARRANTY
Durlable, Afforable, Quality Frameset We offer 6years quality warranty for the Frameset including the handlebars by H9 V2.
Optional for lifetime warranty.
CRASH REPLACEMENT
We hope you don't need this but if you have a crash, we offer a 30% crash replacement discount on all wheels and framesets. Please contact us and we’ll do our very best to help you and ride again ASAP.
