R11 SUPER LIGHT RIM BRAKE BIKE FRAMESET
R11 SUPER LIGHT RIM BRAKE BIKE FRAMESET
R11 SUPER LIGHT RIM BRAKE BIKE FRAMESET
R11 SUPER LIGHT RIM BRAKE BIKE FRAMESET
R11 SUPER LIGHT RIM BRAKE BIKE FRAMESET
R11 SUPER LIGHT RIM BRAKE BIKE FRAMESET
Load image into Gallery viewer, R11 SUPER LIGHT RIM BRAKE BIKE FRAMESET
Load image into Gallery viewer, R11 SUPER LIGHT RIM BRAKE BIKE FRAMESET
Load image into Gallery viewer, R11 SUPER LIGHT RIM BRAKE BIKE FRAMESET
Load image into Gallery viewer, R11 SUPER LIGHT RIM BRAKE BIKE FRAMESET
Load image into Gallery viewer, R11 SUPER LIGHT RIM BRAKE BIKE FRAMESET
Load image into Gallery viewer, R11 SUPER LIGHT RIM BRAKE BIKE FRAMESET

R11 SUPER LIGHT RIM BRAKE BIKE FRAMESET

Regular price $1,591.92

Unit price per

Size

Frameset: R11 Frame+Fork+Handlebar+Seatpost

Sizes:  49cm,52cm,54cm,56cm,59cm

Handlebar Size: 380mm,400mm,420mm,440mm

Stem Size: 90mm/100mm/110mm/120mm

Material: High Modulus Toray T1000 Carbon Fiber

Color: Dark Olive / Chromatic Grey / Baltic Red / Blue Spectrum / Pink Opal / Snowfrost White

Carbon Weave: UD

Groupset Compatible: Machine and Di2 compatible

BB: BB86

Rear Dropout: 130*QR

Rear derailleur hanger: Replacable

Headtube: Taper 1-1/8” to 1-1/2”

Fork:  Direct Mount Fork

Fork Offset: 45˚

Brake: Direct Mount Rim Brake

Max Tire Width: 30mm

Cable: Internal cable route, partial outside

Frame Weight: 850g(54cm)

Fork Weight: 390g

Seatpost Weight: 204g

Accessories: Di2 cover 2PCS
                     1PC Spare Rear Hanger

Limited Rider Weight: 105KG

Warranty: 3 Years



Geometry:



Size Dimension L
Reach
M
Stack
A
Top Tube Length
B
Head Tube Length
C
Seat Tube Angle
D
Head Tube Angle
E
BB Drop
F
Chain Stay
G
Wheel Base
H
BB to Front Wheel
I
Fork Length
J
Fork Rake
K
Seat Tube Length
49CM 373 514 520 110 74° 72.5° 69 410 965 565 370 45 455
52CM 384 523.5 535 120 74° 72.5° 69 410 975 579.5 370 45 475
54cm 385 541 545 136 73.5° 73° 69 410 975 580.2 370 45 495
56CM 394.5 578 560 155 73.5° 73° 69 410 990 594.9 370 45 515
59CM 398 579 575 175 73° 73.5° 69 410 995 600 370 45 535

Sizing & Fit:

The charts below show our recommended sizes based on height, but there are some other factors, like arm and leg length, that determine a great fit.

That’s why you’ll see some overlap in our recommendations.

Size XS
49CM
S
52CM
M
54CM
L
56CM
XL
59CM
Rider Height 165-173CM 170-178CM 175-183CM 180-188CM 185-193CM
