G21 DB STD Gravel Bike
Regular price $5,356.00
Unit price per
Frame Size: 45cm,49cm, 52cm, 54cm, 54cm, 56cm, 58cm, 60cm
Color: Chromatic Grey / Baltic Red / Blue Spectrum / Pink Opal / White Frost
UCI Approved: Yes
Frame:
YOELEO G21 Gravel Frame
Material: High Modulus Toray 800 Carbon Fiber
Rear Dropout: 12*142mm Through Axle
Rear Derailleur Hook: Replaceable
Weight: 980g+/-50g (49cm)
Fork
YOELEO G21 Fork
Material: Carbon
Head Tube: 1-1/2" Straight
Axle Dimension: 12 x 100 mm
Brake: Flat Mount
Weight: 420g+/-15g
Handlebar
YOELEO H21 Handlebar
Handlebar Size: 400mm/420mm/440mm
Stem Size: 90mm/100mm/110mm/120mm
Weight: 340g+/-15g (420x90)
Groupset
Shifter: Shimano GRX RX600
Rear Derailleur: Shimano GRX
Crank: Shimano FC-RX600
Cassette: Shimano HG700, 11 speed
Chain: Shimano CN-HG601
Brake: Shimano SHIMANO GRX Hydraulic Disc Brake Caliper
Rotor: Front 160mm/Rear 160mm
Wheelset
SAT C35|35 DB PRO OFFSET CX/GRAVEL
Thru Axle: 12*100/12*142
KENDA Tires 700*45C
Limited Rider Weight: 110KG
Warranty: 6 Years
LIGHTWEIGHT
G21 MONSTER GRAVEL EXPLORE NATURE, CONQUER CHALLENGES
G21 is good chooice for gravel racing or long-distance gravel riding
EPS+LATEX PRODUCTION TECH FOR HANDLEBAR AND FRAME
Moulded by one piece monobloc with EPS+LATEX tech makes the handlebar much stiffer and smoother internally, yet easier for cable routing.
As previously mentioned the G21 is moulded by new manufacturing process called EPS+Latex Tech. Unlike traditional methods like nylon bladders, latex is very flexible and can stretch, so the inside of the frame can be moulded more consistently. This new tech makes G21 incredibly smooth internally eliminating fold lines and creases for a more uniformed internal wall smoothness resulting in a stronger frame. It also simplifies the cable routing process and with this new tech, the frameset weight remains lower due to the extra resin overflow rate is higher and spreads more evenly during the moulding process.
Our H21 gravel handlebar are using the same tech as well.
FULLY INTERNAL CABLING
Internal cable routing results in external clean lines and improved aerodynamics with the cables completely hidden from view within our fully internal H21 integrated handlebar. The internal cable routing system is not only adding to the aesthetic qualities of the frame, but also makes cleaning the frame a simpler process.
TONS OF MOUNTS
This G21 has tons of mounting for bottle cages, fork panniers, rear panniers, and mudguards on both front and rear sides. We even make the front triangle high enough to ensure riders can mount a frame bag without sacrificing two bottle carrying capacity on the bike.
MASSIVE TIRE CLEARANCE
Up to 53c means you can fit a MTB 29 inch tire when you need to tackle bigger obstacles or to ride in very challenging terrain. However, smaller tire sizes like 45c are recommended for muddy condition rides and for a bike setup with mud guards to ensure there is enough room for mud built-up during the ride.
EXTRA COMPLIANCE FOR BETTER CONTROL
We purposely choose D-Shaped seatpost to give the rider a little bit of compliance on the rough road surface, combined with a bigger tire to act as its main suspension. G21 allows the rider to ignore small obstacles and focus on bike control.
6 YEARS OR LIFETIME WARRANTY
Durlable, Afforable, Quality Frameset We offer 6years quality warranty for the Frameset including the handlebars by H21.
Optional for lifetime warranty.
CRASH REPLACEMENT
We hope you don't need this but if you have a crash, we offer a 30% crash replacement discount on all wheels and framesets. Please contact us and we’ll do our very best to help you and ride again ASAP.
We always want to delivery the best products to our customers, we improved our G21 for 2023 to delivery the best performance
